Vacuum generator
VAD-1/4
9394
GTIN 4052568001858
Vendor Festo
Regular price
$149.36
Unit price
VAD-1/4 is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
Factory shipments may take up to one week. Festo Fast items typically ship the next business day. Contact us for specific shipping estimates.
VAD-1/4
Regular price
$149.36
Unit price
VAD-1/4 is backordered and will ship as soon as it is back in stock.
| Nominal width of Laval nozzle | 1 mm |
|---|---|
| Type code | VAD |
| Mounting position | Any |
| Ejector characteristics | High vacuum |
| Design | T-shape |
| Symbol | 991482 |
| Operating pressure | 1.5 bar ... 10 bar |
| Max. vacuum | 0.8 |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
| Information on operating and pilot media | Operation with oil lubrication possible (required for further use) |
| Temperature of medium | -20 °C ... 80 °C |
| Ambient temperature | -20 °C ... 80 °C |
| Type of mounting | With through-hole |
| Pneumatic connection 1 | G1/4 |
| Pneumatic connection 3 | G1/4 |
| Vacuum connection | G1/4 |
| Note on materials | Free of copper and PTFE |
| Housing material | Die-cast aluminum |
