Power supply unit
CACN-3A-1-10-G2
8149581
GTIN 4052568572181
Vendor Festo
Regular price
$375.60
Unit price
CACN-3A-1-10-G2 is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
Factory shipments may take up to one week. Festo Fast items typically ship the next business day. Contact us for specific shipping estimates.
CACN-3A-1-10-G2
Regular price
$375.60
Unit price
CACN-3A-1-10-G2 is backordered and will ship as soon as it is back in stock.
| Width | 42 mm |
|---|---|
| Height | 130 mm |
| Length | 160 mm |
| Mounting position | Free convection |
| Primary supply | 1-phase |
| Input current | 1.3 - 3.1 A |
| Nominal output voltage DC | 24 V |
| Nominal output current | 10 A |
| Input voltage range AC | 100 V ... 240 V |
| Power failure buffering | 20 ms |
| Mains frequency | 45 Hz ... 65 Hz |
| Certification | c UL us - Listed (OL) |
| CE marking (see declaration of conformity) | As per EU EMC directive As per EU low voltage directive |
| LABS conformity | VDMA24364 zone III |
| Storage temperature | -40 °C ... 85 °C |
| Relative air humidity | 95 % |
| Degree of protection | IP20 |
| Ambient temperature | -25 °C ... 70 °C |
| Product weight | 1168 g |
| Type of mounting | With H-rail |
| Note on materials | RoHS-compliant |
