Pilot valve
VOFX-LT-M32C-MY-G18-SG18-1B2
8119587
GTIN 4052568466022
Vendor Festo
- Valve function
- 3/2, closed, monostable
- Normal nominal flow rate (normalized to DIN 1343)
- 50 l/min
- Pneumatic connection 1
- G1/8
- Operating pressure
- -0.9 bar - 8 bar
Regular price
$109.37
Unit price
VOFX-LT-M32C-MY-G18-SG18-1B2 is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
Factory shipments may take up to one week. Festo Fast items typically ship the next business day. Contact us for specific shipping estimates.
VOFX-LT-M32C-MY-G18-SG18-1B2
Regular price
$109.37
Unit price
VOFX-LT-M32C-MY-G18-SG18-1B2 is backordered and will ship as soon as it is back in stock.
| Valve function | 3/2, closed, monostable |
|---|---|
| Actuation type | Electrical |
| Width | 22 mm |
| Standard nominal flow rate | 50 l/min |
| Pneumatic working port | G1/8 |
| Operating voltage | 24V DC |
| Operating pressure | -0.9 bar ... 8 bar |
| Design | Directly controlled poppet valve |
| Reset method | Mechanical spring |
| Degree of protection | IP65 |
| Nominal width | 1.3 mm |
| Type code | VOFX |
| Exhaust air function | With flow control option |
| Sealing principle | Soft |
| Mounting position | Any |
| Manual override | Detenting |
| Type of control | Direct |
| Pilot air supply port | Internal |
| Flow direction | Non-reversible |
| Symbol | 00991135 |
| Switching time off | 46 ms |
| On switching time | 31 ms |
| Duty cycle | 100% |
| Coil characteristics | 24 V DC: 3.0 W |
| Permissible voltage fluctuations | +/- 10 % |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
| Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
| Temperature of medium | -10 °C ... 50 °C |
| Ambient temperature | -10 °C ... 50 °C |
| Product weight | 160 g |
| Electrical connection | 3-pinForm BPlugas per EN 175301-803 |
| Pneumatic connection 1 | G1/8 |
| Pneumatic connection 2 | G1/8 |
| Pneumatic connection 3 | M5 |
| Note on materials | Contains paint-wetting impairment substancesRoHS-compliant |
| Seals material | NBR |
| Housing material | PA |
