Connecting cable
MHJ9-KMH-2,5-HF
567505
GTIN 4052568100681
Vendor Festo
Regular price
$83.82
Unit price
MHJ9-KMH-2,5-HF is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
Factory shipments may take up to one week. Festo Fast items typically ship the next business day. Contact us for specific shipping estimates.
MHJ9-KMH-2,5-HF
Regular price
$83.82
Unit price
MHJ9-KMH-2,5-HF is backordered and will ship as soon as it is back in stock.
connecting cable MHJ9-KMH-2,5-HF Additional functions=(* Spark arresting, * Reduction of holding current with energy recovery, * Safety shut-off), Mounting type=(* Optional, * with through hole, * with top-hat rail), Assembly position=Any, Product weight=98 g, Electrical connection=(* Straight socket / straight socket / cable, * 2-pin / 2-pin / 4-wire)
| Additional functions | Spark arrestingReduction of holding current with energy recoverySafety shut-off |
|---|---|
| Mounting type | Optionalwith through holewith top-hat rail |
| Assembly position | Any |
| Product weight | 98 g |
| Electrical connection | Straight socket / straight socket / cable2-pin / 2-pin / 4-wire |
| Operating voltage range DC | 12 ... 53 V |
| Polarity protected | for operating voltage |
| Note on operation | Power supply unit must be able to supply at least 1.85 A without voltage drop |
| Information on power consumption | Low-current phase 2.8 W, high-current phase 17.1 W, per channel |
| Duty cycle | 100%Observe notes on operating the solenoid valves |
| Trigger signal range DC | 3 ... 30 V |
| Note on feeder current | Linear rise0.09 - 0.44 mA with a trigger signal of 3 - 15 V0.44-15.44 mA with a trigger signal of 15-30 V |
| Input resistance | 34 kOhm |
