Plug
NECU-L3G8-C2
565710
GTIN 4052568100070
Vendor Festo
- Electrical connection
- Screw terminal - Plug, straight
- Connection cross section
- 0.2 mm² - 2.5 mm²
Regular price
$64.86
Unit price
NECU-L3G8-C2 is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
Factory shipments may take up to one week. Festo Fast items typically ship the next business day. Contact us for specific shipping estimates.
NECU-L3G8-C2
Regular price
$64.86
Unit price
NECU-L3G8-C2 is backordered and will ship as soon as it is back in stock.
| Type code | NECU |
|---|---|
| Contact durability | 100 |
| Electrical connection | 8-pinScrew terminalPlug, straight |
| DC operating voltage range | 0 V ... 30 V |
| Current rating at 40°C | 0 |
| Surge resistance | 4 kV |
| Connection cross section | 0.2 mm² ... 2.5 mm² |
| Ambient temperature | -40 °C ... 85 °C |
| Note on materials | RoHS-compliant |
| Contamination level | 3 |
| Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
| Housing material | PA |
| Housing colour | Black |
| Material of pin contacts | Copper alloyTin-plated |
| Mounting position | Any |
