Plug
NECU-L3G8-C2-IS
565709
GTIN 4052568100063
Vendor Festo
- Electrical connection
- Screw terminal - Plug, straight
- Connection cross section
- 0.2 mm² - 2.5 mm²
Regular price
$64.86
Unit price
NECU-L3G8-C2-IS is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
Factory shipments may take up to one week. Festo Fast items typically ship the next business day. Contact us for specific shipping estimates.
NECU-L3G8-C2-IS
Regular price
$64.86
Unit price
NECU-L3G8-C2-IS is backordered and will ship as soon as it is back in stock.
| Type code | NECU |
|---|---|
| Explosion prevention and protection | Zone 2 (ATEX)Zone 21 (ATEX)Zone 22 (ATEX)Observe the information on the certificateZone 1 (ATEX) |
| Contact durability | 100 |
| Electrical connection | Screw terminal8-pinPlug, straight |
| DC operating voltage range | 0 V ... 30 V |
| Current rating at 40°C | 0 |
| Surge resistance | 4 kV |
| Connection cross section | 0.2 mm² ... 2.5 mm² |
| Ambient temperature | -40 °C ... 85 °C |
| Note on materials | RoHS-compliant |
| Contamination level | 3 |
| Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
| Housing material | PA |
| Housing colour | Blue |
| Material of pin contacts | Copper alloyTin-plated |
| Mounting position | Any |
