Flow sensor
SFAB-1000U-HQ12-2SA-M12-EX2
565409
GTIN 4052568212582
Vendor Festo
- Flow characteristic curve, end value
- 1000 l/min
- Operating medium
- Compressed air as per ISO 8573-1:2010 [7:4:4] - Nitrogen
- Operating pressure
- 0 bar - 10 bar
- Pneumatic connection
- For tubing O.D. 12 mm
Regular price
$914.78
Unit price
SFAB-1000U-HQ12-2SA-M12-EX2 is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
Factory shipments may take up to one week. Festo Fast items typically ship the next business day. Contact us for specific shipping estimates.
SFAB-1000U-HQ12-2SA-M12-EX2
Regular price
$914.78
Unit price
SFAB-1000U-HQ12-2SA-M12-EX2 is backordered and will ship as soon as it is back in stock.
flow sensor SFAB-1000U-HQ12-2SA-M12-EX2 With rotatable display and integrated QS fittings. Authorisation=(* RCM Mark, * c UL us - Recognized (OL)), CE mark (see declaration of conformity)=(* to EU directive for EMC, * to EU directive explosion protection (ATEX)), ATEX category Gas=II 3G, Explosion ignition protection type Gas=Ex nA IIC T5 X Gc, ATEX category Dust=II 3D
| Authorisation | RCM Markc UL us - Recognized (OL) |
|---|---|
| CE mark (see declaration of conformity) | to EU directive for EMCto EU directive explosion protection (ATEX)in accordance with EU RoHS directive |
| ATEX category Gas | II 3G |
| Explosion ignition protection type Gas | Ex nA IIC T5 X Gc |
| ATEX category Dust | II 3D |
| Explosion ignition protection type Dust | Ex tc IIIB T80°C X Dc IP54 |
| Explosion-proof ambient temperature | 0°C <= Ta <= +50°C |
| Certificate issuing department | UL E322346 |
| Materials note | Conforms to RoHS |
| Measured variable | Flow rate Consumption |
| Direction of flow | UnidirectionalP1 -> P2 |
| Measuring principle | Thermal |
| Flow measurement range initial value | 10 l/min |
