Basic valve
LOE-D-MINI-U
546431
GTIN 4052568352967
Vendor Festo
- Normal nominal flow rate (normalized to DIN 1343)
- 5783.9 l/min
- Operating pressure
- 0 bar - 16 bar
Regular price
$96.56
Unit price
Basic valve LOE-D-MINI-U is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
Factory shipments may take up to one week. Festo Fast items typically ship the next business day. Contact us for specific shipping estimates.
LOE-D-MINI-U
Regular price
$96.56
Unit price
Basic valve LOE-D-MINI-U is backordered and will ship as soon as it is back in stock.
lubricator LOE-D-MINI-U Without threaded connection plates with FRB threaded pin, with metal bowl guard. Size=Mini, Series=D, Assembly position=Vertical +/- 5°, Design structure=proportional standard mist lubricator, Max. oil capacity=1,53 oz(l)
| Size | Mini |
|---|---|
| Series | D |
| Assembly position | Vertical +/- 5° |
| Design structure | proportional standard mist lubricator |
| Max. oil capacity | 1.53 oz(l) |
| Bowl guard | Metal bowl guard |
| Operating pressure | 0 ... 240 Psi |
| Standard nominal flow rate | 45.5 cfm |
| Operating medium | Compressed air in accordance with ISO8573-1:2010 [7:4:4]Inert gases |
| Note on operating and pilot medium | Lubricated operation not possible |
| Corrosion resistance classification CRC | 2 - Moderate corrosion stress |
| Storage temperature | 14 ... 140 °F |
| Air purity class at output | Compressed air in accordance with ISO8573-1:2010 [7:4:-]Inert gases |
