Solenoid coil
MSFW-110-50/60-EX
536933
GTIN 4052568049126
Vendor Festo
- Electrical connection
- 3-pin - Plug flags with connection diagram as per Festo standard for MSSD-F
- Type of mounting
- With knurled nut
- Coil characteristics
- 110 V AC: 50/60 Hz, initial power 9.0 VA, holding power 7.0 VA
- Degree of protection
- IP65
Regular price
$38.56
Unit price
MSFW-110-50/60-EX is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
Factory shipments may take up to one week. Festo Fast items typically ship the next business day. Contact us for specific shipping estimates.
MSFW-110-50/60-EX
Regular price
$38.56
Unit price
MSFW-110-50/60-EX is backordered and will ship as soon as it is back in stock.
solenoid coil MSFW-110-50/60-EX With knurled nut and spring washer. Assembly position=Any, Min. pickup time=10 ms, Duty cycle=100%, Power factor cos {phi}=0,7, Characteristic coil data=110 V AC: 50/60 Hz, pick-up power 9 VA, holding power 7 VA
| Assembly position | Any |
|---|---|
| Min. pickup time | 10 ms |
| Duty cycle | 1 |
| Power factor cos {phi} | 0.7 |
| Characteristic coil data | 110 V AC: 50/60 Hz, pick-up power 9 VA, holding power 7 VA |
| Permissible frequency fluctuation | '+/- 5 % |
| Permissible voltage fluctuation | '+/- 10 % |
| ATEX category Gas | II 3G |
| Explosion ignition protection type Gas | Ex nA IIC T4 X Gc |
| ATEX category Dust | II 3D |
| Explosion ignition protection type Dust | Ex tc IIIC T130°C X Dc IP65 |
| Explosion protection certification outside the EU | EPL Dc (CN)EPL Gc (CN) |
| Explosion-proof ambient temperature | '-5°C <= Ta <= +40°C |
