Active carbon filter
LFX-D-MINI
532776
GTIN 4052568086206
Vendor Festo
- Pneumatic connection 1
- Battery module
- Max. standard flow rate for air quality class
- 360 l/min
- Ambient temperature
- -10 °C - 60 °C
- Operating pressure
- 0 bar - 16 bar
- Structural design
- Active carbon filter - Fiber filter
Regular price
$156.23
Unit price
LFX-D-MINI is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
Factory shipments may take up to one week. Festo Fast items typically ship the next business day. Contact us for specific shipping estimates.
LFX-D-MINI
Regular price
$156.23
Unit price
LFX-D-MINI is backordered and will ship as soon as it is back in stock.
| Size | Mini |
|---|---|
| Type code | LFX |
| Series | D |
| Mounting position | Vertical +/- 5° |
| Design | Active carbon filterFiber filter |
| Bowl guard | Metal bowl guard |
| Symbol | 991519 |
| Operating pressure | 0 bar ... 16 bar |
| Recommended maximum standard flow | 360 l/min |
| Max. standard flow rate for air quality class | 360 l/min |
| Operating medium | Inert gasCompressed air as per ISO 8573-1:2010 [1:4:2] |
| Information on operating and pilot media | Operation with oil lubrication possible (required for further use) |
| Storage temperature | -10 °C ... 60 °C |
| Air quality class at the output | Compressed air as per ISO 8573-1:2010 [1:4:1]Inert gas |
| Temperature of medium | 5 °C ... 30 °C |
| Residual oil content | ≤ 0.003 mg/m³ |
| Ambient temperature | -10 °C ... 60 °C |
| Product weight | 283 g |
| Type of mounting | Optionally:With mounting bracketLine installation |
| Pneumatic connection | Without sub-base |
| Pneumatic connection 1 | Battery module |
| Pneumatic connection 2 | Battery module |
| Note on materials | RoHS-compliantFree of copper and PTFE |
| Housing material | Die-cast zinc |
| Material of bowl | PC |
