Intermediate position attachment
SLG-Z-8/12-A
525680
GTIN 4052568161903
Vendor Festo
Regular price
$405.20
Unit price
SLG-Z-8/12-A is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
Factory shipments may take up to one week. Festo Fast items typically ship the next business day. Contact us for specific shipping estimates.
SLG-Z-8/12-A
Regular price
$405.20
Unit price
SLG-Z-8/12-A is backordered and will ship as soon as it is back in stock.
intermediate position attachment SLG-Z-8/12-A For linear drive SLG Assembly position=Any, Design structure=Stop as rotary drive system, Position detection=For proximity sensor, Operating pressure=1 - 8 bar, Operating medium=Compressed air in accordance with ISO8573-1:2010 [7:-:-]
| Assembly position | Any |
|---|---|
| Design structure | Stop as rotary drive system |
| Position detection | For proximity sensor |
| Operating pressure | 1 ... 8 bar |
| Operating medium | Compressed air in accordance with ISO8573-1:2010 [7:-:-] |
| Note on operating and pilot medium | Lubricated operation possible (subsequently required for further operation) |
| Corrosion resistance classification CRC | 2 - Moderate corrosion stress |
| Ambient temperature | '-10 ... 60 °C |
| Product weight | 33.5 g |
| Mounting type | With through-hole and dowel pin |
| Pneumatic connection | M3 |
| Materials note | Free of copper and PTFE |
| Material stops | Steel, nickel-plated |
