OR block
OS-PK-3-6/3
4232
GTIN 4052568000578
Vendor Festo
- Valve function
- OR function
- Pneumatic connection 1
- PK-3
- Normal nominal flow rate (normalized to DIN 1343)
- 100 l/min
- Operating pressure
- 1.6 bar - 8 bar
- Type of mounting
- Front panel mounting
Regular price
$270.14
Unit price
OS-PK-3-6/3 is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
Factory shipments may take up to one week. Festo Fast items typically ship the next business day. Contact us for specific shipping estimates.
OS-PK-3-6/3
Regular price
$270.14
Unit price
OS-PK-3-6/3 is backordered and will ship as soon as it is back in stock.
OR block OS-PK-3-6/3 Valve function=OR function, Pneumatic connection, port 1=PK-3, Pneumatic connection, port 2=PK-3, Mounting type=Front panel installation, Standard nominal flow rate=100 l/min
| Valve function | OR function |
|---|---|
| Pneumatic connection, port 1 | PK-3 |
| Pneumatic connection, port 2 | PK-3 |
| Mounting type | Front panel installation |
| Standard nominal flow rate | 100 l/min |
| Operating pressure | 1.6 ... 8 bar |
| Ambient temperature | '-10 ... 60 °C |
| Material housing | POM |
| Operating medium | Compressed air in accordance with ISO8573-1:2010 [7:-:-] |
| Nominal size | 2.5 mm |
| Assembly position | Any |
| Note on operating and pilot medium | Lubricated operation possible (subsequently required for further operation) |
| Medium temperature | '-10 ... 60 °C |
