Pressure gauge
OH-22-RT
4131
GTIN 4052568000554
Vendor Festo
Regular price
$78.23
Unit price
OH-22-RT is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
Factory shipments may take up to one week. Festo Fast items typically ship the next business day. Contact us for specific shipping estimates.
OH-22-RT
Regular price
$78.23
Unit price
OH-22-RT is backordered and will ship as soon as it is back in stock.
pressure indication OH-22-RT Assembly position=Any, Operating pressure=1,4 - 8 bar, Operating medium=Compressed air in accordance with ISO8573-1:2010 [7:-:-], Note on operating and pilot medium=Lubricated operation possible (subsequently required for further operation), Medium temperature=-10 - 45 °C
| Assembly position | Any |
|---|---|
| Operating pressure | 1.4 ... 8 bar |
| Operating medium | Compressed air in accordance with ISO8573-1:2010 [7:-:-] |
| Note on operating and pilot medium | Lubricated operation possible (subsequently required for further operation) |
| Medium temperature | '-10 ... 45 °C |
| Ambient temperature | '-10 ... 45 °C |
| Product weight | 25 g |
| Mounting type | Control panel installation in diameter 22.5 |
| Pneumatic connection | G1/8 |
| Materials note | Conforms to RoHS |
