One-way flow control valve
GGO-1/4-3/8
3634
GTIN 4052568000479
Vendor Festo
- Valve function
- Flow control non-return function
- Standard nominal flow rate in flow control direction
- 950 l/min
- Pneumatic connection 1
- G1/4
- Adjusting element
- Roller lever
Regular price
$882.64
Unit price
GGO-1/4-3/8 is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
Factory shipments may take up to one week. Festo Fast items typically ship the next business day. Contact us for specific shipping estimates.
GGO-1/4-3/8
Regular price
$882.64
Unit price
GGO-1/4-3/8 is backordered and will ship as soon as it is back in stock.
| Type code | GGO |
|---|---|
| Valve function | Flow control non-return function |
| Pneumatic connection 1 | G1/4 |
| Pneumatic connection 2 | G¼ |
| Actuation type | Mechanical |
| Adjusting element | Roller lever |
| Type of mounting | With through-hole |
| Standard nominal flow rate in flow control direction | 950 l/min |
| Standard nominal flow rate in non-return direction | 1150 l/min |
| Operating pressure | 0.03 bar ... 8 bar |
| Ambient temperature | -10 °C ... 60 °C |
| Housing material | Wrought aluminum alloy |
| Mounting position | Any |
| Symbol | 991466 |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] |
| Information on operating and pilot media | Operation with oil lubrication possible (required for further use) |
| Temperature of medium | -10 °C ... 60 °C |
| Product weight | 400 g |
| Seals material | NBR |
