Pneumatic valve
VLX-2-3/8-MS
34433
GTIN 4052568115166
Vendor Festo
- Structural design
- Diaphragm valve
- Valve function
- 2/2, closed, monostable
- Fitting connection
- G3/8
- Normal nominal flow rate (normalized to DIN 1343)
- 3800 l/min
- Medium pressure
- 1 bar - 10 bar
Regular price
$342.09
Unit price
VLX-2-3/8-MS is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
Factory shipments may take up to one week. Festo Fast items typically ship the next business day. Contact us for specific shipping estimates.
VLX-2-3/8-MS
Regular price
$342.09
Unit price
VLX-2-3/8-MS is backordered and will ship as soon as it is back in stock.
pneumatic valve VLX-2-3/8-MS Brass version Design structure=Diaphragm valve, Type of actuation=pneumatic, Sealing principle=soft, Assembly position=Any, Mounting type=Line installation
| Design structure | Diaphragm valve |
|---|---|
| Type of actuation | pneumatic |
| Sealing principle | soft |
| Assembly position | Any |
| Mounting type | Line installation |
| Process valve connection | G3/8 |
| Nominal size | 13 mm |
| Valve function | 2/2 closed, monostable |
| Flow direction | non reversible |
| Medium pressure | 1 ... 10 bar |
| Exhaust-air function | not throttleable |
| Type of reset | Air spring |
| Type of piloting | Piloted |
