Sub-base
VABS-S7-BE-B-G14-V14-A
2999476
GTIN 4052568268039
Vendor Festo
Regular price
$311.14
Unit price
VABS-S7-BE-B-G14-V14-A is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
Factory shipments may take up to one week. Festo Fast items typically ship the next business day. Contact us for specific shipping estimates.
VABS-S7-BE-B-G14-V14-A
Regular price
$311.14
Unit price
VABS-S7-BE-B-G14-V14-A is backordered and will ship as soon as it is back in stock.
sub-base VABS-S7-BE-B-G14-V14-A Assembly position=Any, Pilot air supply=Internal, Operating pressure=2 - 8 bar, Flow rate Kv ventilation=2,2 m3/h, Flow rate Kv exhaust=8,6 m3/h
| Assembly position | Any |
|---|---|
| Pilot air supply | Internal |
| Operating pressure | 2 ... 8 bar |
| Flow rate Kv ventilation | 2.2 m3/h |
| Flow rate Kv exhaust | 8.6 m3/h |
| Operating medium | Compressed air in accordance with ISO8573-1:2010 [-:-:-] |
| Corrosion resistance classification CRC | 4 - Very high corrosion stress |
| Protection class | IP65 |
| Product weight | 250 g |
| Mounting type | with through hole |
| Pneumatic connection, port 1 | G1/4 |
| Pneumatic connection, port 2 | Flange 1/4NAMUR port pattern |
| Pneumatic connection, port 3 | G1/4 |
