Air solenoid valve
MHA1-M1H-3/2O-0,6-PI
197026
GTIN 4052568081522
Vendor Festo
- Valve function
- 3/2, open, monostable
- Normal nominal flow rate (normalized to DIN 1343)
- 10 l/min
- Operating pressure
- 0 bar - 6 bar
Regular price
$57.12
Unit price
MHA1-M1H-3/2O-0,6-PI is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
Factory shipments may take up to one week. Festo Fast items typically ship the next business day. Contact us for specific shipping estimates.
MHA1-M1H-3/2O-0,6-PI
Regular price
$57.12
Unit price
MHA1-M1H-3/2O-0,6-PI is backordered and will ship as soon as it is back in stock.
solenoid valve MHA1-M1H-3/2O-0,6-PI manifold block valve for individual and battery mounting, particularly small design, with plug connection below (plug-in). Valve function=3/2 open, monostable, Type of actuation=electrical, Width=10 mm, Standard nominal flow rate=10 l/min, Operating pressure=0 - 6 bar
| Valve function | 3/2 open, monostable |
|---|---|
| Type of actuation | electrical |
| Width | 10 mm |
| Standard nominal flow rate | 10 l/min |
| Operating pressure | 0 ... 6 bar |
| Design structure | Poppet valve with spring return |
| Type of reset | mechanical spring |
| Protection class | IP40 |
| Authorisation | c CSA us - Recognized (OL)c UL us - Recognized (OL) |
| Nominal size | 0.7 mm |
| Grid dimension | 10 mm |
| Exhaust-air function | throttleable |
| Sealing principle | soft |
