On/off valve
HEP-D-MIDI
193249
GTIN 4052568015121
Vendor Festo
- Operating pressure
- 0 bar - 16 bar
- Actuation type
- Pneumatic
Regular price
$208.61
Unit price
On/off valve HEP-D-MIDI is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
Factory shipments may take up to one week. Festo Fast items typically ship the next business day. Contact us for specific shipping estimates.
HEP-D-MIDI
Regular price
$208.61
Unit price
On/off valve HEP-D-MIDI is backordered and will ship as soon as it is back in stock.
on-off valve HEP-D-MIDI Part number: 193249 Classic For service units, without threaded connection plates with FRB threaded pin Modern alternatives can be found by entering the first four characters of the type code in the search field.
| Design structure | Piston slide |
|---|---|
| Type of actuation | pneumatic |
| Sealing principle | soft |
| Exhaust-air function | not throttleable |
| Manual override | None |
| Type of reset | mechanical spring |
| Valve function | 3/2 closed, monostable |
| Operating pressure | 0 ... 16 bar |
| Pilot pressure | 3 ... 16 bar |
| Operating medium | Compressed air in accordance with ISO8573-1:2010 [7:4:4]Inert gases |
| Note on operating and pilot medium | Lubricated operation possible (subsequently required for further operation) |
| Corrosion resistance classification CRC | 2 - Moderate corrosion stress |
| Materials note | Conforms to RoHS |
