On/off valve
HEP-3/8-D-MINI
193245
GTIN 4052568079765
Vendor Festo
- Pneumatic connection 1
- G3/8
- Normal nominal flow rate (normalized to DIN 1343)
- 1600 l/min
- Operating pressure
- 0 bar - 16 bar
- Actuation type
- Pneumatic
Regular price
$189.51
Unit price
On/off valve HEP-3/8-D-MINI is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
Factory shipments may take up to one week. Festo Fast items typically ship the next business day. Contact us for specific shipping estimates.
HEP-3/8-D-MINI
Regular price
$189.51
Unit price
On/off valve HEP-3/8-D-MINI is backordered and will ship as soon as it is back in stock.
on-off valve HEP-3/8-D-MINI Part number: 193245 Classic Used in conjunction with service units. Modern alternatives can be found by entering the first four characters of the type code in the search field.
| Design structure | Piston slide |
|---|---|
| Type of actuation | pneumatic |
| Sealing principle | soft |
| Exhaust-air function | not throttleable |
| Manual override | None |
| Type of reset | mechanical spring |
| Valve function | 3/2 closed, monostable |
| Operating pressure | 0 ... 16 bar |
| Pilot pressure | 3 ... 16 bar |
| C value | 7.7 l/sbar |
| b value | 0.3 |
| Standard nominal flow rate | 1,600 l/min |
| Operating medium | Compressed air in accordance with ISO8573-1:2010 [7:4:4]Inert gases |
