Filter regulator LFR-1-D-7-O-MAXI
192599
Vendor Festo
Regular price
$553.59
Unit price
Filter regulator LFR-1-D-7-O-MAXI is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
Factory shipments may take up to one week. Festo Fast items typically ship the next business day. Contact us for specific shipping estimates.
Filter regulator LFR-1-D-7-O-MAXI
Regular price
$553.59
Unit price
Filter regulator LFR-1-D-7-O-MAXI is backordered and will ship as soon as it is back in stock.
filter regulator LFR-1-D-7-O-MAXI Part number: 192599 Classic Without pressure gauge, maximum outlet pressure 7 bar. Modern alternatives can be found by entering the first four characters of the type code in the search field.
| Size | Maxi |
|---|---|
| Series | D |
| Actuator lock | Rotary knob with lock |
| Assembly position | Vertical +/- 5° |
| Grade of filtration | 40 µm |
| Condensate drain | manual rotary |
| Design structure | Filter regulator without pressure gauge |
| Max. condensate volume | 80 cm3 |
| Bowl guard | Metal bowl guard |
| Pressure gauge | Prepared for G1/4 |
| Operating pressure | 1 ... 16 bar |
| Pressure regulation range | 0.5 ... 7 bar |
| Max. pressure hysteresis | 0.4 bar |
