Air line lubricator
LOE-D-MAXI
192577
GTIN 4052568152406
Vendor Festo
- Operating pressure
- 0 bar - 16 bar
- Minimum flow rate for lubricator function
- 10 l/min
Regular price
$297.86
Unit price
Air line lubricator LOE-D-MAXI is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
Factory shipments may take up to one week. Festo Fast items typically ship the next business day. Contact us for specific shipping estimates.
LOE-D-MAXI
Regular price
$297.86
Unit price
Air line lubricator LOE-D-MAXI is backordered and will ship as soon as it is back in stock.
lubricator LOE-D-MAXI Part number: 192577 Classic Without threaded connection plates with FRB threaded pin, with metal bowl guard. Modern alternatives can be found by entering the first four characters of the type code in the search field.
| Size | Maxi |
|---|---|
| Series | D |
| Assembly position | Vertical +/- 5° |
| Design structure | proportional standard mist lubricator |
| Max. oil capacity | 190 cm3 |
| Bowl guard | Metal bowl guard |
| Operating pressure | 0 ... 16 bar |
| Minimum flow rate for lubricator function | 10 l/min |
| Operating medium | Compressed air in accordance with ISO8573-1:2010 [7:4:4]Inert gases |
| Note on operating and pilot medium | Lubricated operation possible (subsequently required for further operation) |
| Corrosion resistance classification CRC | 2 - Moderate corrosion stress |
| Storage temperature | '-10 ... 60 °C |
| Air purity class at output | Compressed air in accordance with ISO8573-1:2010 [7:4:-]Inert gases |
