Air line lubricator
LOE-D-MINI
192575
GTIN 4052568014995
Vendor Festo
- Operating pressure
- 0 bar - 16 bar
- Minimum flow rate for lubricator function
- 3 l/min
Regular price
$96.56
Unit price
Air line lubricator LOE-D-MINI is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
Factory shipments may take up to one week. Festo Fast items typically ship the next business day. Contact us for specific shipping estimates.
LOE-D-MINI
Regular price
$96.56
Unit price
Air line lubricator LOE-D-MINI is backordered and will ship as soon as it is back in stock.
lubricator LOE-D-MINI Part number: 192575 Classic Without threaded connection plates with FRB threaded pin, with metal bowl guard. Modern alternatives can be found by entering the first four characters of the type code in the search field.
| Size | Mini |
|---|---|
| Series | D |
| Assembly position | Vertical +/- 5° |
| Design structure | proportional standard mist lubricator |
| Max. oil capacity | 45 cm3 |
| Bowl guard | Metal bowl guard |
| Operating pressure | 0 ... 16 bar |
| Minimum flow rate for lubricator function | 3 l/min |
| Operating medium | Compressed air in accordance with ISO8573-1:2010 [7:4:4]Inert gases |
| Note on operating and pilot medium | Lubricated operation not possible |
| Corrosion resistance classification CRC | 2 - Moderate corrosion stress |
| Storage temperature | '-10 ... 60 °C |
| Air purity class at output | Compressed air in accordance with ISO8573-1:2010 [7:4:-]Inert gases |
