Illuminating seal
MF-LD-230AC
19144
GTIN 4052568022488
Vendor Festo
Regular price
$36.55
Unit price
MF-LD-230AC is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
Factory shipments may take up to one week. Festo Fast items typically ship the next business day. Contact us for specific shipping estimates.
MF-LD-230AC
Regular price
$36.55
Unit price
MF-LD-230AC is backordered and will ship as soon as it is back in stock.
| Type code | MF-LD |
|---|---|
| Switching position indication | LED |
| Type of mounting | On air solenoid valve with M3 central screw |
| Product weight | 1.6 g |
| Electrical connection | Rectangular design MSF |
| Nominal operating voltage AC | 230 V |
| Surge resistance | 4 kV |
| Protective earth connection | Available |
| Nominal power luminous seal | 0.33 W |
| Permissible voltage fluctuations | +/- 10 % |
| Degree of protection | IP65 |
| Ambient temperature | -25 °C ... 85 °C |
| CE marking (see declaration of conformity) | As per EU low voltage directive |
| Contamination level | 3 |
| Housing material | TPE-U(PU) |
