Interface
CAMC-F-PN
1911916
GTIN 4052568249311
Vendor Festo
Regular price
$529.98
Unit price
CAMC-F-PN is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
Factory shipments may take up to one week. Festo Fast items typically ship the next business day. Contact us for specific shipping estimates.
CAMC-F-PN
Regular price
$529.98
Unit price
CAMC-F-PN is backordered and will ship as soon as it is back in stock.
| Dimensions W x L x H | 19 mm x 90 mm x 65 mm |
|---|---|
| CE marking (see declaration of conformity) | As per EU EMC directive |
| Storage temperature | -25 °C ... 70 °C |
| Relative air humidity | 5 - 95 %Non-condensing |
| Degree of protection | IP20In mounted state |
| Ambient temperature | 0 °C ... 50 °C |
| Product weight | 75 g |
| Type of mounting | Plug-in module for CMMP-AS...-M3 |
| Note on materials | Contains paint-wetting impairment substancesRoHS-compliant |
| Mounting position | Any |
| Type code | CAMC |
| Protocol | PROFINET |
| Communication profile | FHPP |
| Baud rate | 10/100 Mbit/s (full/half) |
| Topologies | LineStarRing |
| Media redundancy | MRP |
| IP address allocation | DCPFCT |
| Fieldbus interface | 2x RJ45 socket |
| Minimum cycle time | 1 ms |
| LED indicators | System faultEthernet communication activityBus errorEthernet line monitoring |
| Configuration support | GSDML |
| Parameterization | FCT |
| Additional functions | Real-time class 1IRT-compatibleSNMPLLDPMRPDCPPROFIenergyConformance class B |
