Differential pressure regulator
LRLL-10-32-UNF-QS-5/32-U
190903
Vendor Festo
Regular price
$47.11
Unit price
LRLL-10-32-UNF-QS-5/32-U is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
Factory shipments may take up to one week. Festo Fast items typically ship the next business day. Contact us for specific shipping estimates.
LRLL-10-32-UNF-QS-5/32-U
Regular price
$47.11
Unit price
LRLL-10-32-UNF-QS-5/32-U is backordered and will ship as soon as it is back in stock.
differential pressure regulator LRLL-10-32-UNF-QS-5/32-U Part number: 190903 Without manometer, with male thread and QS plug connector.
| Controller function | Differential pressure, constant |
|---|---|
| Pneumatic connection, port 1 | UNF10-32 |
| Mounting type | Threaded |
| Inlet pressure 1 | 0 ... 9 bar |
| Ambient temperature | 0 ... 60 °C |
| Material housing | PBT-reinforced |
| Operating medium | Compressed air in accordance with ISO8573-1:2010 [7:-:-] |
| Assembly position | Any |
| Note on operating and pilot medium | Lubricated operation possible (subsequently required for further operation) |
| Product weight | 9 g |
| Material of threaded plug | Brass |
| Materials note | Conforms to RoHS |
