Cable socket
ASI-SD-FK
18785
GTIN 4052568022389
Vendor Festo
Regular price
$15.76
Unit price
ASI-SD-FK is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
Factory shipments may take up to one week. Festo Fast items typically ship the next business day. Contact us for specific shipping estimates.
ASI-SD-FK
Regular price
$15.76
Unit price
ASI-SD-FK is backordered and will ship as soon as it is back in stock.
| Type code | ASI-SD |
|---|---|
| Type of mounting | With through-hole |
| Product weight | 6.8 g |
| Electrical connection | 2-pinSocket, straight |
| DC operating voltage range | ≤ 75 V |
| Operating voltage range AC | ≤ 60 V |
| Current rating | 0.125 |
| Connection cross section | 1.5 mm² |
| Degree of protection | IP65 |
| Ambient temperature with flexible cable installation | -5 °C ... 50 °C |
| Storage temperature | -30 °C ... 85 °C |
| Note on materials | RoHS-compliant |
| Housing material | PA |
| Material of pin contacts | Bronze |
| Mounting position | Any |
