Push-in cap
QSC-6-100
130705
GTIN 4052568024260
Vendor Festo
- Pneumatic connection 1
- For pneumatic tubing outside diameter 6 mm
- Temperature-dependent operating pressure
- -0.95 bar - 14 bar
- Ambient temperature
- -10 °C - 80 °C
Regular price
$1.37
Unit price
QSC-6-100 Push-in cap is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
Factory shipments may take up to one week. Festo Fast items typically ship the next business day. Contact us for specific shipping estimates.
QSC-6-100
Regular price
$1.37
Unit price
QSC-6-100 Push-in cap is backordered and will ship as soon as it is back in stock.
push-in cap QSC-6-100 Size=Standard, Assembly position=Any, Container size=100, Design structure=Push/pull principle, Operating pressure complete temperature range=-0,95 - 6 bar
| Fitting Type | Cap Plug |
|---|---|
| Size | Standard |
| Assembly position | Any |
| Container size | 100 |
| Design structure | Push/pull principle |
| Operating pressure complete temperature range | '-0.95 ... 6 bar |
| Temperature dependent operating pressure | '-0.95 ... 14 bar |
| Operating medium | Compressed air in accordance with ISO8573-1:2010 [7:-:-]Water as per manufacturer's declaration at www.festo.com |
| Note on operating and pilot medium | Lubricated operation possible |
| Corrosion resistance classification CRC | 1 - Low corrosion stress |
| Ambient temperature | '-10 ... 80 °C |
| Maritime classification | see certificate |
| Product weight | 3.5 g |
| connection 1 | 6mm outside diameter, for tubing |
| Colour of release ring | blue |
| Materials note | Conforms to RoHS |
| Material housing | PBT |
| Material release ring | POM |
| Material of tubing seal | NBR |
| Material of tube retaining claw | High alloy steel, non-corrosive |
