Exhaust air flow control valve
GRE-1/8
10351
GTIN 4052568002183
Vendor Festo
- Valve function
- Sound pressure flow control function
- Standard nominal flow rate in flow control direction
- 520 l/min
- Pneumatic connection 1
- G1/8
- Adjusting element
- Slotted screw
Regular price
$27.90
Unit price
GRE-1/8 is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
Factory shipments may take up to one week. Festo Fast items typically ship the next business day. Contact us for specific shipping estimates.
GRE-1/8
Regular price
$27.90
Unit price
GRE-1/8 is backordered and will ship as soon as it is back in stock.
exhaust air flow control valve GRE-1/8 With sintered metal silencer. Valve function=Flow control – silencer function, Pneumatic connection, port 1=G1/8, Adjusting element=Slotted head screw, Mounting type=Threaded, Standard nominal flow rate in flow control direction=520 l/min
| Valve function | Flow control – silencer function |
|---|---|
| connection 1 | G1/8 |
| Adjusting element | Slotted head screw |
| Mounting type | Threaded |
| Standard nominal flow rate in flow control direction | 520 l/min |
| Standard flow rate 6 -> 0 bar | 0 ... 520 l/min |
| Ambient temperature | '-10 ... 70 °C |
| Assembly position | Any |
| Operating pressure complete temperature range | 0 ... 10 bar |
| Operating medium | Compressed air in accordance with ISO8573-1:2010 [7:-:-] |
| Note on operating and pilot medium | Lubricated operation possible (subsequently required for further operation) |
| Medium temperature | '-10 ... 70 °C |
| Nominal tightening torque | 12 Nm |
| Design | Flow Control Muffler |
